Industrial Rugged Android Tablet Monitor / IP65 Touch Screen Monitor

Industrial Rugged Android Tablet Monitor / IP65 Touch Screen Monitor
Industrial Rugged Android Tablet Monitor / IP65 Touch Screen Monitor

Large Image :  Industrial Rugged Android Tablet Monitor / IP65 Touch Screen Monitor

Product Details:
Place of Origin: China
Brand Name: LONGYU
Certification: CE RoHS
Model Number: LYA101K20I-W-BT
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: TBA
Packaging Details: 1-5pcs/CTN, Safe, Firm, suitable for international shipping
Delivery Time: 7-10 Work Days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 10000PCS/Month

Industrial Rugged Android Tablet Monitor / IP65 Touch Screen Monitor

Description
Operating System: Android11.0 Size: 10.1 Inch
IP Grade: Industrial Grade IP65 Dustproof And Water Proof Luminance: 300cd/ M²
Angle Of View: Full Perspective Gigabit Ethernet Interface: 1-Route 10 / 100 Mbps Ethernet Port
High Light:

Rugged Android Tablet Monitor

,

Android Tablet Monitor IP65

,

IP65 Touch Screen Monitor

Product Description



1280X800 IP65 Waterproof Touch Screen Industrial Rugged Android Tablet Monitors



LYA101K20I-W-BT is a high-performance embedded integrated touch screen with the industrial core core Micro RK3568 (quad-core A55 main frequency 2.0 Ghz) CPU as the core. The product features a high-resolution 10.1-inch LED LCD display (resolution of 1280 * 800) and a 10-point capacitive touch screen. It supports USB, Ethernet, DI / DO, RS232, RS485, CAN, WIFI, BT interface, etc. It is suitable for industrial automation control, man-machine interface, small and medium-sized medical analyzer and other industry applications. Built-alone 0.8T NPU can be used for lightweight AI applications.



Key Features:

CPU:RK3568 / Cortex A55 4 core main frequency at 2.0GHZ

Running memory:2GB/4GB

EMMC:16GB/32GB/64GB/128GB

GPU:Mali-G52 1-Core-2EE



Size:10.1 Inch

Resolving power:1280 * 800

Touch form:Capactive 10 touch

Luminance:300 cd/ m²(Select a 450cd / m² s)



Working temperature:-10℃ ~ 60℃

Storage temperature:-20℃ ~ 70℃

Operating humidity:5-90 RH%



Product Performance



  Performance Details







System

CPU RK3568 / Cortex A55 4 core main frequency at 2.0GHZ
Operating System Android11.0/Ubuntu18.04/Linux 4.19
Running memory 2GB/4GB
EMMC 16GB/32GB/64GB/128GB
GPU Mali-G52 1-Core-2EE





Display

Size 10.1 Inch
Resolving power 1280 * 800
Touch form Capactive 10 touch
Luminance 300 cd/ m²(Select a 450cd / m² s)
Angle of view Full perspective





Material

Material quality Plastic face frame, metal back cover
Way to stall Flat, outer, embedded
Product size 260 * 178 * 41mm
IP protection grade Industrial grade IP65 dustproof water proof (operating face)



Power

Power interface 3 PIN*2.54mm terminal DC24V provides power supply
Power input 12V-30V(Recommended value 24V)



Environmental Characteristics

Working temperature -10℃ ~ 60℃
Storage temperature -20℃ ~ 70℃
Operating humidity 5-90 RH%
Serial port

3 RS232,2 RS232 / RS485 / CAN switch;

6-way TTL serial port (reuse with serial port)

Audio interface 1-way MIC interface
Gigabit Ethernet interface 1-Route 10 / 100 /1000 Mbps Ethernet port
HDMI interface 1 HDMI output, with a maximum resolution of 3840 * 2160
TF 1-Route TF card interface
SIM 1 Standard drawer-type interface with reserved eSIM interface
RTC 1 Built-in supercapacitor
WIFI/BT 2.4G WIFI / BT4.2
GPS The GPS function 4G module should be replaced
4G Expand mini PCIE 4G module
GPIO 4 input and output: 2 optical coupling input, 2 relay dry contact output;
USB2.0 1 Vertical plug interface USB 2.0,4 horizontal plug interface USB 2.0,1 built-in row pin (USB 2.0)
USB3.0 1 Vertical USB 3.0 (switch through dial switch)



Warranty Instruction



Our company will provide you the following services with this card and invoice (or copy) in accordance with the provisions listed in this warranty card:

  • The machine is guaranteed for three years. Free warranty for the first year; Only the cost fee will be charged in the second and third years, and the service fee will be charged after three years
  • The warranty period starts from the date of invoice
  • Please keep this warranty card and invoice (or copy) properly. You can enjoy warranty service only if you show them together during the period
  • During the warranty period, failure occurs due to the following conditions:, We will charge a certain fee at its discretion:



Company introduction



Wuhan Longyu Intelligent Technology Co., Ltd has a strong R & D, production, sales and management team. Relying on independently developed embedded computer software system and hardware platform technology, we have carefully developed a series of products, the main products include: man-machine interface touch screen, industrial tablet computer all-in-one, ARM industrial motherboard, industrial display, etc. We strive to promote the upgrading of China's manufacturing industry, the research and development of products are widely used in intelligent transportation, automation equipment, terminal self-help equipment, industrial control, electric power, military industry, finance, network security, Marine manufacturing, medical instruments, numerical control, instrumentation, scientific research and other industries, with many well-known enterprises at home and abroad to maintain long-term stable cooperation.
