| Material: | Plastic Face Frame, Metal Back Cover | Resolution: | 1280 * 800 |
|---|---|---|---|
| Touch Form: | Capacitive 10 Touch | Operating System: | Android10.0 |
| CPU: | RK3399 (dual Cortex-A72 Large Core+four Cortex-A53 Small Core Structure) 1.8GHZ | Running Memory: | 2GB/4GB |
| EMMC: | 16GB/32GB/64GB/128GB | IP Grade: | Industrial Grade IP65 Dustproof And Water Proof |
| Working Temperature: | -10℃ ~ 60℃ | Storage Temperature: | -20℃ ~ 70℃ |
| High Light: | 7 Inch IP65 Panel PC,IP65 Panel PC CE,7 Inch Panel PC Dustproof |
||
7 Inch Panel PC for Beauty Therapy
LYA101K20C is a high-performance embedded integrated touch screen with the industrial Rockchip RK3568 (quad-core A55 main frequency 2.0 Ghz) CPU as the core. The product features a high-resolution 10.1-inch LED LCD display (resolution 1920 * 1080) and a 10-point capacitive touch screen. It supports USB, Ethernet, DI / DO, RS232, RS485, CAN, WIFI, BT interface, etc. It is suitable for industrial automation control, HMI, small and medium-sized medical analyzer and other industry applications. Built-alone 0.8T NPU can be used for lightweight AI applications.
|
System |
CPU processor | RK3399 (dual Cortex-A72 large core+four Cortex-A53 small core structure) 1.8GHZ |
| Operating System | Android10.0 | |
| Running memory | 1GB | |
| EMMC | 8GB | |
| GPU | GE8300 | |
|
Display |
Size | 7.0 Inch |
| Resolving power | 1280 * 800 | |
| Touch form | Capactive 10 touch | |
| Luminance | 300 cd/ m² | |
| Angle of view | Full perspective | |
|
Material |
Material quality | Plastic face frame, metal back cover |
| Way to stall | Flat, outer, embedded | |
| Dimension | 192 * 128 * 28mm | |
| IP protection grade | Industrial grade IP65 dustproof water proof (operating face) | |
|
Source |
Power interface | 3 PIN*2.54mm terminal DC24V provides power supply |
| Power input | 10.6V-13.2V(Recommended value 12V) | |
|
Environmental Character istics |
Working temperature | -10℃ ~ 60℃ |
| Storage temperature | -20℃ ~ 70℃ | |
| Operating humidity | 5-90 RH% | |
| Serial port | 2 Route RS232 / TTL, 2 route TTL； | |
| Audio interface | 1-way MIC interface | |
| Gigabit Ethernet interface | 1-Route 10 / 100 /1000 Mbps Ethernet port | |
| HDMI interface | 1 HDMI output, with a maximum resolution of 3840 * 2160 | |
| TF | 1-Route TF card interface | |
| SIM card | 1 Standard drawer-type interface with reserved eSIM interface | |
| RTC | 1 Road Hardware Clock | |
| WIFI/BT | 2.4G WIFI | |
| 4G interface | Expand mini PCIE 4G module | |
| GPIO interface | 4-way GPIO, IO direction is input and output configurable, and IO level is 5.0V； | |
| USB2.0 | 1 USB 2.0,3 built-in pins (USB 2.0) | |
| USB3.0 | 1 Horizontal insertion interface, USB 3.0 |
2 Product Performance
